U Series / Vertical / horizontal tilting head

U1250

5-Axis Vertical/Horizontal Machining Center

The DEPU U1250 is a high-precision, high-load, high-efficiency vertical and horizontal tilting head 5-axis CNC machining center. Manufactured under the DEPU U-series line, it is designed for heavy-duty, complex manufacturing and parts processing.

Price on request (USD)
Contact us to confirm availability.

Reference configuration. Confirm tooling, workholding and spindle options for your application.

X / Y / Z travel
1,250 / 1,000 / 1,250
mm
Max. workpiece
Ø1,250 × 1,000 mm
diameter × height
Uniform table load
2,500 kg
reference configuration
Max. spindle speed
10,000 rpm
reference spindle
Technical specificationsU1250 / Reference configuration

U1250
Technical overview

Review the key specifications and validate the working envelope against your part, fixture, and tool assembly.

Technical data · U1250
ParameterUnitU1250
Working range
X / Y / Z travelmm1250/1000/1250
Max. workpiece sizemmØ 1250*1000
Uniform table loadkg2500
B / C rotary rangedeg360°/ -120°~- 0°
Rapid traverse
Rapid traverse - X / Y / Zm/min30/30/30
Rapid traverse - B / Crpm/min8/50
Spindle
Tool interfaceHSK-A100
Max. spindle speedrpm10,000
Spindle powerkW50/70
Spindle torqueN.m400/560 (S1/S6)
Tool magazine
Tool magazine capacitytools40
Max. tool length / weightmm/kg350/20
Machine and control
Machine weightkg29000
Machine dimensions (L x W x H)mm7200x8100x4300
Product details / U1250

Product details

The U1250 gives manufacturers greater flexibility when tackling challenging part geometries. Its vertical and horizontal machining capability supports versatile production, from heavy castings to intricate components, with fewer workpiece repositioning steps.

U1250 features

Excellent Machining Accessibility

The machine offers excellent access and visibility within the machining area, making it quick and easy to load, unload, and set up workpieces and tools. This provides operators with a more convenient and comfortable working experience.

High Load Capacity

The U1250 features X-, Y-, and Z-axis travels of 1,250 / 1,000 / 1,250 mm, accommodates workpieces up to Ø1,250 × 1,000 mm, and supports a maximum uniformly distributed table load of 2,500 kg.

High Structural Rigidity

The machine features a wall-type structural design, with all axes fully supported throughout their entire travel range. This provides excellent structural rigidity and enables the machine to achieve its full cutting performance, even under demanding machining conditions.

Optimized Machining Area

During vertical machining, the spindle centerline can travel across the entire worktable surface, helping eliminate tool transition errors and ensuring consistent machining accuracy across the full working area.

Wide Range of Spindle Configurations

The U1250 features an HSK-A100 spindle with a maximum speed of 10,000 rpm, spindle power ratings of 50/70 kW, and torque ratings of 400/560 N·m (S1/S6). This configuration allows the machine to accommodate different workpiece materials, cutting conditions, and productivity requirements.

Applications & workpiecesLet geometry lead

Complex surfaces.
Practical questions.

From machining complex blades to producing multi-sided features, the right machining approach starts with understanding your part's geometry.

Large die-cast housing being machined on a tilting-head five-axis center

Multi-Sided / Die-Cast Housings

Large Castings.
Machined in One Setup.

Box-shaped castings often require machining on multiple faces. A tilting-head configuration provides greater tool access to different surfaces while allowing the workpiece to remain securely clamped.

Case Consultation
Impeller being machined on a five-axis center with a tilting head

Impellers and Blades.
High-Speed Surface Finishing.

Complex curved surfaces and internal flow passages require precise tool access and controlled machining conditions. A tilting-head configuration can provide the flexibility needed for machining intricate impeller and blade geometries.

Large filter housing with deep cavities and narrow slots

5G Filter Housings.
Deep Cavities. Thin Walls. Narrow Slots.

Large 5G filter housings often feature deep cavities, thin walls, and narrow slots. A tilting-head machining center can provide improved tool access to these complex features, helping reduce the need for multiple setups.

Your Application / U1250

Your part.
Our starting point.

Tell us about your project, including the part geometry, material, and the machining results you're looking for.

The U1250 model will be preselected in your inquiry.
